Orbinox: HidroCFD R&D update and slurry / mining valve solutions

In March 2026 Orbinox received HAZITEK 2025 support for the HidroCFD R&D project. For Ukrainian plants this is a signal that the manufacturer is investing in hydraulic works while already offering a working range of knife-gate and pinch valves for abrasive slurries, tailings and mineral processing.

On 23 March 2026 Orbinox announced HAZITEK 2025 support for the HidroCFD R&D project, co-financed by the Basque Government and the European Union through the European Regional Development Fund 2021–2027 (ERDF/FEDER). The company has not published a full technical description of the model on its news page; this article records only the confirmed funding fact. A year earlier Orbinox received HAZITEK 2024 for the BULKHAND project — the R&D line is continuous, not a one-off announcement.

The practical offer for mining, ore concentration, tailings and slurry lines is the product range already on the market. Model EP (SER.75) is a bi-directional lug-type knife gate valve with a polyurethane-lined ductile-iron body. It is intended for abrasive fluids and suspended solids in mining, pulp & paper, power, chemical and food plants. Manufacturer data: full bore, 10 bar working pressure, EN 1092 PN10 / ASME B16.5 Class 150 connections, DN50–DN600 (larger on request). Actuation: handwheel and pneumatic cylinder.

For heavy corrosive-abrasive slurries Orbinox offers PA pinch valves: full-bore enclosed heavy-duty design, elastomer sleeve as the only part in contact with the media. Sizes DN25–DN300, pressure up to 10 bar. Actuators: handwheel, gearbox, pneumatic cylinder; electric and hydraulic on request. Applications: mining, water treatment, FGD, pulp & paper, chemicals, power plants, cement and ceramics. Operating benefit: almost no mechanics in the flow path and sleeve replacement instead of a major body overhaul.

The mining portfolio also includes slurry knife gates VG, WG and HG — from medium-duty wafer valves to wide-body and high-pressure designs with rubber sleeves for tailings and concentrate pipelines. For Ukrainian sites (concentrators, tailings, pulp mills, cement, hydraulic works) selection follows media, pressure, flow direction and actuator type. Prices and stock availability are not stated in this news item.

CSC-AUTOMATION is the official Orbinox distributor in Ukraine. Contact the valves team to select a knife gate, pinch valve or hydraulic-works unit against the project specification.

Keywords: Orbinox, HidroCFD, HAZITEK 2025, knife gate valve, slurry valve, EP SER.75, PA pinch valve, VG WG HG, mining, tailings, abrasive slurry, polyurethane lining, CSC-AUTOMATION, industrial valves Ukraine.
