Кодова рейка, тип WCS2-CS55-M1-S000000-L010000

WCS2-CS55-M1-S000000-L010000. Part Number 70135876-100000

General specifications

Code rail height 55 mm

Total length 10000 mm

Start position 0 mm

Radius of bend ≥ 500 mm

Ambient conditions

Operating temperature -40 ... 100 °C (-40 ... 212 °F)

Storage temperature -40 ... 100 °C (-40 ... 212 °F)

Installation temperature 10 ... 60 °C (50 ... 140 °F)

Mechanical specifications

Material thickness 0.5 mm

Tension loading ≤ 4500 N

Material stainless steel 1.4310 / AISI 301

Thermal expansion coefficient 1.6 x 10-5 / K

Mass 175 g / m

Manufacturing tolerance ± 1 mm/m
